Redox Alpha V2 microprocessor  battery charger


Redox Alpha V2 microprocessor  battery charger

A new improved version of the popular Redox company’s Alpha charger. The Redox Alpha V2 is inter alia equipped with an actualized software ensuring a long and stable operation of the device. Additionally, a big radiator which discharges the heat very efficiently was mounted on the top of the charger. It is possible to change the charging current of the charger and to monitor the voltage of each cell while the process of charging!


Dimensions: 134 x 86 x 26 mm

Operational voltage: DC 11.0~18.0 V

Output power:

– Maximum charging power 50W

– Maximum discharging power 5W

Charging current: 0.1~5.0A

Discharging current: 0.1~1.0A

Balancing current intensity : 300 mAh/cell

Number of supported NiCD/NiMH cells: 1~15 cells

Number of supported Li-Po/Fe/Ion cells: 1~6 cells

Supported Pb cells : 2~20V

Weight (without wiring):  400 g

Charger’s inbuilt memory: maximum of 5 battery packs

Battery pack cycling function

4 programming buttons

Inbuilt sockets:

– balancer sockets 2s, 3s, 4s, 5s, 6s  ,

– Gold 4 mm  sockets,

– Jack type socket (powered by 12V DC)  ,

– an optional temperature sensor socket,


The set includes:

the Redox Alpha V2  charger,

a 12V DC power wire (Jack – crocodiles),

1 x Gold 4 mm Adapter – DEAN  plug,

Additional extending adapters for the Gold 4 mm adapter –  DEAN plugs:

1 x DEAN adapter plug – Crocodiles

1 x DEAN adapter plug – Servo socket (FUTABA type)

1 x DEAN adapter plug – spark plug dummy  (for charging 1,5V clips)

1 x DEAN adapter plug – BEC socket



Out of stock
